    Full Or Partial Automatic Wire Stripping Machine Stripping Wire AWG32 To AWG18 Strip head:1 to 30mm

    Ask Lasest Price
    Brand Name : Fortune Sky
    Model Number : BJ-880
    Certification : CCC,CE
    Price : USD1-USD9999
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram , Paypal
    Supply Ability : 100 pcs per month
    Delivery Time : 2-3 working days
    • Product Details
    • Company Profile

    Full Or Partial Automatic Wire Stripping Machine Stripping Wire AWG32 To AWG18 Strip head:1 to 30mm

    This full or partial automatic wire stripping machine for stripping wire from 32AWG to 14AWG uses a hybrid drive microcomputer full LCD operating system, cutting, stripping, one time completion, but also the front half stripping with twisted wire, protect the integrity of the wire, special wire can instantly change the size of wire specifications.


    Full or partial automatic wire stripping machine cut strip 20mm wire working vedios:


    Model No.BJ-600BJ-650BJ-800BJ-880
    Main FunctionCut wire,both-ends strippingCut wire,both-ends stripping,intermediate strip, (wire twisting for BJ-880)
    Cutting wire core

    0.1-4.0mm2

    (30AWG-14AWG)

    0.1-4.0mm2

    (30AWG-14AWG)x2

    0.1-2.0mm2

    (32AWG-14AWG)x2

    0.1-2.5mm2

    (30AWG-14AWG)x2

    Processing Speed(decided by wire material)2000-8000 pcs/hour4000-16000 pcs/hour2000-8000 pcs/hour
    Cutting Length0.1-9999.9mm
    No. Of Intermediate Stripping013
    Stripping Length

    Strip head: 1-30mm

    Strip tail: 0.1-15mm

    Strip head: 1-30mm

    Strip tail: 0.1-30mm

    Strip head: 1-50mm

    Strip tail: 0.1-30mm

    Strip head: 1-30mm

    Strip tail: 0.1-20mm

    Accuracy of outlet inlet motorMute hybrid stepping motor 0.1mm per stepping
    Other functionsAutomatic wire inlet & outlet, timing
    Driving Mode4 wheels
    Dimension(mm)380x250x320420x297x345420x297x345420x297x345
    Net Weight25283235
    Blade MaterialImport Tungsten Steel/High speed steel
